High quality horn subwoofer
OMNITRONIC PAS-118 Subwoofer

OMNITRONIC

High quality horn subwoofer

OMNITRONIC PAS-118 Subwoofer

Item no. 11039640

Features

High quality horn subwoofer

  • Powerful subwoofer
  • Cubic housing
  • For a combination with the PAS-tops
  • High sound-pressure
  • Very high durability
  • Housing made of several layer, 18-mm birch plywood
  • Scratch-resistant lacquer surface
  • Impact-resistant steel grille with acoustic foam
  • With flange for top speaker installation
  • Four optional swivel castors can be attached on the rear panel
  • Very large amplification systems can be realized via several PAS-speaker-systems and the respective power amplifiers
  • Ideal as PA-system or amplification system for medium-sized and large discotheques
Technical specifications
Frequency range:38 - 400 Hz
Width:71 cm
Height:72 cm
Depth:51 cm
Weight:59,25 kg
Rated power:800 W RMS
Program power:1600 W
Components:45 cm woofer (18")
Connection: 2 Speaker sockets
Sensitivity:98 dB
Maximum SPL:127 dB
Impedance:8 ohms
Dimensions (H x W x D):710 x 510 x 720 mm
Packaging units
PU EAN Weight Dimensions
1 4026397162622 63,00 kg 78cm x 57cm x 74cm
Accessories
Loading accessories. Please wait...
Support
Spare parts
Loading spareparts. Please wait...
Downloads
User manual
Name Version Language
11039640-Manual-63754-2.300-de_en.pdf (4 MB) 2.300 de_en
Illustration
Catalog pages
Service document
Name Version Language
11039640-Service-6250-1.000-de_en.pdf (127 KB) 1.000 de_en
All images
Name Version Language
11039640-Images.zip
