High quality bassreflex subwoofer
OMNITRONIC PAS-152 Subwoofer

OMNITRONIC

High quality bassreflex subwoofer

OMNITRONIC PAS-152 Subwoofer

Item no. 11039625

Features
  • Powerful bassreflex subwoofer
  • Cubic housing
  • Powerful, dry bass via voluminous housing with bassreflex system
  • For a combination with the PAS tops
  • High sound-pressure
  • Very high durability
  • Housing made of several layer, 18 mm birch plywood
  • Scratch-resistant lacquer surface
  • Impact-resistant steel grille with acoustic foam
  • With flange for top speaker installation
  • Four optional swivel castors can be attached on the rear panel
  • Very large amplification systems can be realized via several PAS speaker systems and the respective power amplifiers
  • Ideal as PA system or amplification system for medium-sized and large discotheques
Technical specifications
Rated power:1200 W RMS
Program power:2400 W
Components:2 x 38 cm woofer (2 x 15")
Connection: 2 Speaker sockets
Sensitivity:99 dB
Maximum SPL:130 dB
Impedance:4 ohms
Dimensions (H x W x D):840 x 510 x 635 mm
Weight:60 kg
Frequency range:45 - 200 Hz
Packaging units
PU EAN Weight Dimensions
1 4026397162615 63,65 kg 57cm x 70cm x 90cm
Accessories
Loading accessories. Please wait...
Support
Spare parts
Loading spareparts. Please wait...
Downloads
User manual
Name Version Language
00063754.pdf 2.30 de/en
Illustration
Name Version Language
00006279.jpg 0.00 de/en/fr/es
00006456.jpg 0.00 es/fr/en/de
Catalog pages
Name Version Language
00097790.pdf 25.00 de
00097890.pdf 25.00 en
Data sheet
Name Version Language
00006249.pdf 1.10 de/en
All images
Name Version Language
11039625.zip
