Powerful 2-chamber bandpass subwoofer
OMNITRONIC PAS-18 Subwoofer

mpn11039615-omnitronic-pas-18-subwoofer-MainBild

mpn11039615-omnitronic-pas-18-subwoofer-Bild-1

OMNITRONIC

Powerful 2-chamber bandpass subwoofer

OMNITRONIC PAS-18 Subwoofer

The article is no longer in our assortment.

Item no. 11039615

Features

Powerful 2-chamber bandpass subwoofer

Cubic housing
For a combination with the PAS tops
High sound pressure
Very high durability
Housing made of several layer, 18 mm birch plywood
Scratch-resistant lacquer surface
Impact-resistant steel grille with acoustic foam
Can be used lying or standing
With two flanges for top speaker installation
Suitable castors optional
Very large amplification systems can be realized via several PAS speaker-systems and the respective power amplifiers
Ideal as PA system or amplification system for medium-sized and large discotheques

Technical specifications

Frequency range:	35 - 500 Hz
Width:	53.5 cm
Height:	60 cm
Depth:	79.5 cm
Weight:	52.60 kg
Rated power:	800 W RMS
Program power:	1600 W
Components:	45 cm woofer (18")
Connection:	2 Speaker sockets
Sensitivity:	98 dB
Maximum SPL:	127 dB
Impedance:	8 ohms
Dimensions (H x W x D):	535 x 795 x 600 mm

Packaging units

PU	EAN	Weight	Dimensions
1	4026397162608	57,20 kg	55cm x 63cm x 84cm

Accessories

Loading accessories. Please wait...

Support

Spare parts

Loading spareparts. Please wait...

Downloads

User manual

Name	Version	Language
11039615-Manual-63754-2.300-de_en.pdf (4 MB)	2.300	de_en

Illustration

Name	Version	Language

Catalog pages

Name	Version	Language
11039615-Page-97890-25.00-en.pdf (227 KB)	25.00	en
11039615-Page-97790-25.00-de.pdf (229 KB)	25.00	de

Data sheet

Name	Version	Language
11039615-Datasheet-6341-1.100-de_en.pdf (159 KB)	1.100	de_en

All images

Name	Version	Language
11039615-Images.zip
