Active complete system, 360 W RMS
OMNITRONIC AS-360 Active system

OMNITRONIC

Active complete system, 360 W RMS

OMNITRONIC AS-360 Active system

Item no. 11038802

Features
  • Two-way satellite system consisting of two tops and one subwoofer
  • Perfectly tuned system for demanding home users, DJs, musicians, small parties etc.
  • Easy-to-use complete system
  • Rugged full-range top speaker in a stable wooden housing
  • Tops: with passive 2-way crossover
  • Sub: powerful, dry bass via optimized double vented bandpass system
  • Balanced frequency range with high sound pressure
  • Speaker connection via lockable Speaker-plugs
  • Scratch-resistant lacquer surface
  • Compact speaker system for car transport
Technical specifications
Top:
Rated power:120 W RMS
Program power:180 W
Components:2 x 10 cm woofer (2 x 4"), dome tweeter
Connection: 1 Speaker socket
Sensitivity:90 dB
Maximum SPL:108 dB
Impedance:4 ohms
Dispersion angle:60° x 60°
Crossover frequency:3 kHz
Dimensions (H x W x D):350 x 145 x 170 mm
Subwoofer:
Rated power:140 W RMS
Program power:200 W
Components:20 cm woofer (8")
Sensitivity:96 dB
Maximum SPL:114 dB
Impedance:4 ohms
Dimensions (H x W x D):430 x 320 x 420 mm
Amplifier:
Power supply:230 V AC, 50 Hz
Total power output:360 W RMS
Nominal power output satellite:2 x 120 W RMS
Nominal power output subwoofer:120 W RMS
Active crossover:
Crossover frequency:140 Hz
Inputs:2 x XLR, 2 x RCA
Outputs:2 Speaker sockets
Min. input sensitivity:0.350 V
Control elements:Power switch, Gain control , Sublevel control
LED indicators (per channel):Power
Protection circuits:Short-circuit
Power consumption:500.00 W
Weight:4,5 kg
Frequency range:120 - 20000 Hz
Height:17 cm
Depths:14,5 cm
Width:35 cm
Packaging units
PU EAN Weight Dimensions
1 4026397357493 29,20 kg 48cm x 41cm x 64cm
Accessories
Loading accessories. Please wait...
Support
Spare parts
Loading spareparts. Please wait...
Downloads
User manual
Name Version Language
00040798.pdf 1.00 de/en
Illustration
Name Version Language
Satellite
Product design00037751.pdf
0.00 en
Subwoofer
Product design00040796.pdf
1.20 de/en/fr
All images
Name Version Language
11038802.zip
