Active 2-way speaker system for PA and DJ applications
OMNITRONIC NKB-212A Plastic cabinet active

OMNITRONIC

Active 2-way speaker system for PA and DJ applications

OMNITRONIC NKB-212A Plastic cabinet active

Item no. 11038787

Features
  • 2-way bass-reflex system with 30 cm woofer and 3.5 cm tweeter
  • Mic and line inputs with separate level controls
  • Master control with 2-way tone control and clip LED
  • Line output for linking further active speaker systems
  • Front blue signal LED
  • Stable plastic housing with protective grille and handles
  • Flange for stand installation
  • Can be used as floor monitor, standing, on a speaker stand or wall holder
  • For mobile live and DJ applications
Technical specifications
Power supply:100-240 V AC, 50/60 Hz
Rated power:200 W RMS
Program power:300 W
Components:30 cm woofer (10"), 3.5 cm horn (1.35")
Inputs:
1 Mic:3-pin XLR or 6.3 mm jack, unbal.
1 Line:XLR or stereo RCA
Outputs:
1 Line:3-pin XLR or 6.3 mm jack, unbal.
Maximum SPL:117 dB
Dimensions (H x W x D):592 x 405 x 320 mm
Weight:20 kg
Frequency range:50 - 18000 Hz
Packaging units
PU EAN Weight Dimensions
1 4026397423365 14,55 kg 42,5cm x 37,5cm x 64,5cm
Support
Spare parts
Loading spareparts. Please wait...
Downloads
User manual
Name Version Language
00058981.pdf 1.10 de/en
Catalog pages
Name Version Language
00067075.pdf 21.00 de
00067834.pdf 21.00 en
00086993.pdf 23.00 de
00087571.pdf 23.00 en
Service document
Name Version Language
Circuit diagram00076813.pdf 1.00 de
All images
Name Version Language
11038787.zip
