Full-Range speaker-system for disco or live music with 12" woofer and 800 watts power
OMNITRONIC TMX-1230 3-Way Speaker 800W

Name: OMNITRONIC TMX-1230 3-Way Speaker 800W
Brand: OMNITRONIC

Stock for approx. 12 wk(s)

89,00 €

Find a dealer

Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Features

Full-Range speaker-system for disco or live music with 12" woofer and 800 watts power

Rugged Full-Range speaker-system in a stable wooden housing
30 cm woofer (12") with special, higly temperature resistant vibrating coil
Tweeter with coil-driver for powerful treble
Mid-range membrane loudspeaker for a smooth sound when reproducing speech or singing
With passive 3-way crossover
Powerful bass via voluminous housing and bass-reflex tube
Very high durability
With bar handles
Scratch-resistant, black felt-covering
Strong protective grille for perfect protection
With stable protective steel corners
With flange for speaker-stand installation etc.
Compact speaker-system for car transport
The ideal speaker-system for live music, presentations, bands etc.

Technical specifications

Components:	30 cm woofer (12"), 15 cm mid-range speaker (6"), tweeter
Connection:	2 Speaker sockets
Sensitivity:	96 dB
Dimensions (H x W x D):	655 x 400 x 310 mm
Weight:	14,55 kg
Frequency range:	40 - 18000 Hz
Rated power:	400 W RMS
Program power:	800 W
Size of woofer:	(12") ca. 30 cm
Number of bass-woofer:	1 Pc/Pcs
Height:	65,5 cm
Sensitivity:	96 dB (1W/1m)
Depth:	31 cm
Width:	40 cm
Impedance:	8 Ohm

Packaging units

PU	EAN	Weight	Dimensions
1	4026397101164	16,15 kg	42cm x 32,5cm x 68cm
