Monitor, 10" woofer, 1,35" driver, LF: 150 W RMS, HF: 50 W RMS
OMNITRONIC KM-110A Active Stage Monitor, coaxial

svg
OMNITRONIC

Monitor, 10" woofer, 1,35" driver, LF: 150 W RMS, HF: 50 W RMS

OMNITRONIC KM-110A Active Stage Monitor, coaxial

Stock for approx. 12 wk(s)
199,00
add to cart
Find a dealer
Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Item no. 11038035

Features

Monitor, 10" woofer, 1,35" driver, LF: 150 W RMS, HF: 50 W RMS

  • Active 2-way coaxial stage monitor for live and playback applications
  • Class D/AB biamp power amplifier
  • Power output LF: 150 W RMS
  • Power output HF: 50 W RMS
  • 25 cm bass speaker (10") and 3.5 cm compression driver (1.35")
  • 80° x 80° nominal coverage
  • Bassreflex cabinet provides deep bass and high SPL
  • Line input (XLR/6.3 mm jack)
  • Parallel output (XLR) for linking further active speaker systems
  • Low cut, volume control
  • Dual limiter and overload protection
  • Rugged MDF housing with scratch-resistant lacquer surface and impact-resistant steel grille
  • Flange for stand installation
Technical specifications
Power supply:115/230 V AC, 50/60 Hz
Power consumption:80 W
Power connection:Mains input IEC connector (M) mounting version via Power supply cord with safety plug (provided)
Rated power:150 W RMS LF; 50 W RMS HF
Program power:300 W
Woofer:(10") approx 25 cm
Frequency range:60 - 20000 Hz
Max. SPL:121 dB
Dispersion angle:80° x 80°
Width:48 cm
Height:42 cm
Depth:30 cm
Weight:14,30 kg
Components:25 cm woofer (10"), 3.5 cm driver (1.35")
Input:combination XLR/6.3 mm jack
Parallel output:XLR
Packaging units
PU EAN Weight Dimensions
1 4026397529883 15,85 kg 46cm x 41cm x 54cm
