Rugged full-range speaker-system with 10" woofer and 400 watts power
OMNITRONIC DX-1022 3-Way Speaker 400 W

Name: OMNITRONIC DX-1022 3-Way Speaker 400 W
Brand: OMNITRONIC

Rugged full-range speaker-system with 10" woofer and 400 watts power

OMNITRONIC DX-1022 3-Way Speaker 400 W

Stock for approx. 12 wk(s)

49,90 €

Find a dealer

Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Item no. 11037061

Print product

Product badge

High performance at a low price: the OMNITRONIC DX-series! Available in five differently powered versions, the DX-series provides the right speaker-system for almost every need. The housing with carpet finish is extremely rugged, which makes this series also perfect for mobile DJs.

Features

Rugged full-range speaker-system with 10" woofer and 400 watts power

3-way party speaker-system for disco and rock music
Piezo super tweeters for powerful treble
High-quality horn for smooth mid-range
Optional subbass provides a powerful bass
Very high durability
With tray handles
Stable wooden housing scratch-resistant, black felt-covering
Strong protective grille for perfect protection
Flange for stand installation
With stable protective steel corners
Compact speaker-system for car transport
Ideal for mobile discotheques or for permanent installation in party rooms etc.

Technical specifications

Rated power:	200 W RMS
Program power:	400 W
Woofer:	25 cm (10")
Frequency range:	50 - 18000 Hz
Sensitivity:	95 dB (1W/1m)
Impedance:	8 Ohm
Connections:	2 x Speaker
Number of woofers:	1 pc/pcs
Width:	36 cm
Height:	46,5 cm
Depth:	31 cm
Weight:	8,90 kg
Components:	25 cm woofer (10"), piezo, horn
Connection:	2 Speaker sockets
Sensitivity:	95 dB

Packaging units

PU	EAN	Weight	Dimensions
1	4026397101041	10,00 kg	38cm x 32,5cm x 50cm

Accessories

Loading accessories. Please wait...

Support

Spare parts

Loading spareparts. Please wait...

Downloads

User manual

Name	Version	Language
11037061-Manual-64404-1.400-de_en.pdf (4 MB)	1.400	de_en

Catalog pages

Name	Version	Language
11037061-Page-97782-25.00-de.pdf (260 KB)	25.00	de
11037061-Page-97883-25.00-en.pdf (259 KB)	25.00	en
11037061-Page-115019-27.00-de.pdf (245 KB)	27.00	de
11037061-Page-115456-27.00-en.pdf (245 KB)	27.00	en

Data sheet

Name	Version	Language
11037061-Datasheet-6267-1.000-de_en.pdf (830 KB)	1.000	de_en
11037061-Datasheet-6368-1.000-de_en_fr_es.pdf (830 KB)	1.000	de_en_fr_es

Service document

Name	Version	Language
11037061-Service-9371-de.pdf (15 KB)	0.000	de

All images

Name	Version	Language
11037061-Images.zip

Publications

main catalog 2019 St. E #28

On page: 36

Size: 284 MB
