Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	30.00 W
Power connection:	Mains input via C8 (M) "figure 8" mounting version power supply cord with Euro plug (provided)
Frequency range:	20 - 20000 Hz
S/N ratio:	>80 dB
THD:	<0.1 % at 1 kHz
Control:	IR remote control
Audio player:	CD player, (ID3 tag), Anti-shock, Seamless loop
Sample rate:	44.1 kHz
CD player drive:	Slot in-single CD drive
Display:	MP3 ID3-Tags , play time remaining , play time elapsed; CD-DA play time remaining , play time elapsed , total play time remaining
Connections:	Output: line via 1 x 3-pin XLR Output: line via 1 x stereo RCA Output: rec. via 1 x stereo RCA Output: headphones via 1 x 3.5 mm jack (stereo) mounting version
Music format:	CD, CD-R, CD-RW, CD-DA, MP3
Frame accuracy:	1/75 s
Pitch range:	±16%, ±24%
Converter:	1 bit
Housing design:	(19") 48.3 cm rack installation 1 U
Dimensions:	Width: 48.3 cm Depth: 27 cm Height: 4.45 cm
Weight:	2.95 kg
Remote control
Battery:	2 x 1.5 V AAA Micro R03 zinc carbon included

Packaging units

PU	EAN	Weight	Dimensions
1	4026397402377	3,50 kg	50,5cm x 32,5cm x 10,5cm
4	4026397402384	15,20 kg	53cm x 35,5cm x 48cm

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

Service document

Name	Version	Language
10602413-Service-62251-1.0000-en.pdf (97 KB)	1.0000	en

All images

Name	Version	Language
10602413-Images-.zip

OMNITRONIC CMP-102 CD/MP3 Player

The article is no longer in our assortment.

Check out the alternatives:

No. 10602413

1 U

CD/MP3 player with IR remote control and XLR connectors

1 U flat CD player for permanent installation e.g. in restaurants, fitness studios, retail locations
Audio CD/ CD-R/CD-RW/MP3 CD
Full CBR/VBR MP3 support
Slot-in drive
40 seconds anti-shock protection
Adjustable headphones output (3.5 mm jack) on the front panel
Master output (XLR and RCA)
Recording output (RCA)
Pitch adjustment up to ±24 %, can be deactivated
Cue function
Seamless Loop/Reloop function
Single or continuous play
Random play
Repeat functions: repeat 1, repeat folder, repeat all
Title programming (audio CD)
Comfortable track selection with skip buttons and +10 button
Folder navigation
Alphanumeric LCD with blue backlight
Indication of elapsed time, remain time (MP3 CD) or total remain time (audio CD)
Indication of artist and title name (MP3 CD)
Bargraph display (audio CD)
Pitch adjustment is displayed in %
Rack installation (1 U), rack brackets removable
Control via IR remote control
Sample rate: 44.1 kHz
Pitch range: ±16%, ±24%
(19") 48.3 cm rack installation 1 U
