8-channel PA amplifier with integrated limiter 8 x 150 W/4 ohms
OMNITRONIC MCP-8150 8-Channel Amplifier

svg
OMNITRONIC

8-channel PA amplifier with integrated limiter 8 x 150 W/4 ohms

OMNITRONIC MCP-8150 8-Channel Amplifier

Item no. 10452430

The MCP multichannel PA amplifiers are suitable for versatile applications. For increased power output, separate channels can be combined in pairs in bridge operation. High pass filters and low pass filters which can individually be switched for each channel allow the use as a 2-way system without the need for additional crossovers. Level adjustment is tamper-proof due to recessed potentiometers on the rear side.
Features

8-channel PA amplifier with integrated limiter 8 x 150 W/4 ohms

  • PA amplifier with integrated limiter for multi-zone applications
  • 8 x 150 W/4 ohms
  • 8-ohm bridge operation possible
  • Signal inputs via balanced XLR mounting jacks or terminal blocks
  • Speaker connection via terminal blocks
  • High pass filter, low pass filter can be switched on additionally for each channel
  • Tamper-proof level adjustment on the rear panel
  • 7-fold output meter with clip LED per channel
  • Speaker switch-on delay
  • Groundlift switch against humming
  • Fan cooling
  • Robust steel chassis with aluminum front
  • Complete protection set against short-circuit, overheat, overload, and DC voltage overlay at the outputs
  • Rack installation with 3 units
Technical specifications
Power supply:115/230 V AC, 50/60 Hz
Power consumption:1850,00 W
Output power:max. 1200 W
8 x 150 W RMS (4 ohms)
8 x 100 W RMS (8 ohms)
Frequency range:22 - 25000 Hz
Circuitry:Class AB
Width:48,3 cm
Height:13,35 cm
Depth:31 cm
Weight:16,25 kg
Power output sine:
4 ohms:8 x 150 W
8 ohms:8 x 100 W
8 ohms bridged:4 x 300 W
Damping factor:>200
Distortion factor:0.01 %
SN ratio:90 dB
Channel separation (at 1 kHz):51 dB
Min. input sensitivity:0.77 V
Slew rate:>30 V/µsec
Input impedance:12 kohms (unbalanced), 22 kohms(balanced)
Input connectors:8 x XLR female, 8 x terminal block
Output connectors:8 x terminal block
Control elements:Power switch, level control per channel, crossover on/off per channel, high/low pass per channel, mode switch (stereo/bridged)
Indicators:Level with clip per channel, bridged
Protection circuits:Softstart, short-circuit, overheat, overload and DC voltage
Construction:Steel chassis with aluminum front panel
Dimensions:310 x 482 x 132 mm
Minimum mounting depth:320 mm
Packaging units
PU EAN Weight Dimensions
1 4026397181500 17,30 kg 52cm x 41cm x 22cm
Accessories
Loading accessories. Please wait...
Support
Spare parts
Loading spareparts. Please wait...
Downloads
User manual
Name Version Language
10452430-Manual-53040-1.200-de_en.pdf (2 MB) 1.200 de_en
Catalog pages
Service document
Name Version Language
10452430-Service-8921-1.000-de.pdf (86 KB) 1.000 de
Video file
Name Version Language
10452430-Video-57759-de_en_fr_es.flv (10 MB) 0.000 de_en_fr_es
All images
Name Version Language
10452430-Images.zip
