Technical specifications

Power supply:	230 V AC, 50 Hz
Power consumption:	115 W 1/8 power
Protection class:	Protection class I
Output power:	2 x 250 W RMS (8 ohms) 2 x 400 W RMS (4 ohms)
Power connection:	Power supply cord with safety plug (provided)
Battery:	1 x button cell 3.0 V CR2025 lithium manganese built-in
Frequency range:	20 - 20000 Hz
S/N ratio:	>89 dB
THD:	<0.05 % at 1 kHz
DSP:	Digital signal processor 24 bit with 16 effects
Phantom power:	48 V DC
Control:	IR remote control; Bluetooth
Bluetooth device name:	Bluetooth
Audio player:	USB + SD + Bluetooth
Control elements:	Level control per channel, Master control, tone control, phantom power switch
Connections:	Input: microphone via 8 x 3-pin XLR Input: line via 12 x 6.3 mm jack socket (stereo) mounting version Input: line via 1 x stereo RCA Input: AUX via 2 x 6.3 mm jack socket (stereo) mounting version Output: AUX via 2 x 6.3 mm jack socket (stereo) mounting version Output: rec. via 1 x stereo RCA Output: master via 2 x 3-pin XLR Output: speaker via 2 x speaker built-in socket (F)
Channels:	Input channel: 2 x stereo via jack, 2-band tone control EQ, gain control, panoramacontol
Input channels:	8 x mono via XLR or jack
Equalizer:	Channel: 8 x 2-band tone control mono
Available storage media:	USB devices/SD cards
USB port:	Type A
Color:	Black
Housing design:	(19") 48.3 cm rack installation 3 U
Dimensions:	Width: 48.3 cm Depth: 34 cm Height: 13.35 cm
Weight:	6.55 kg

Packaging units

PU	EAN	Weight	Dimensions
1	4026397683233	8,05 kg	53cm x 42cm x 23cm
2	4026397684230	15,95 kg	44cm x 42cm x 54cm

Spare parts

OMNITRONIC L-1422 Remote Control

Transistor SPP20N60C3

Fan 24V/0,20A 80x80x25 (24S8025H)

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

All images

Name	Version	Language
10040302-Images-.zip

Publications

Move Magazin #2/2023 E

On page: 55

Size:

OMNITRONIC RM-1422FXA USB Rack Power Mixer

Name: OMNITRONIC RM-1422FXA USB Rack Power Mixer
Brand: OMNITRONIC
SKU: 10040302
Price: 399.00 EUR
Availability: LimitedAvailability

19" powered mixer, 2 x 400 W, with 12 channels, DSP FX unit and MP3 player-MainBild

19" powered mixer, 2 x 400 W, with 12 channels, DSP FX unit and MP3 player-Bild-1

OMNITRONIC RM-1422FXA USB Rack Power Mixer

available in approx. 9 wk(s)

399,00 €

Find a dealer

available in approx. 9 wk(s)

List price excl. 19% VAT
Prices in retail stores may vary.

No. 10040302

3 U

19" powered mixer, 2 x 400 W, with 12 channels, DSP FX unit and MP3 player

Audio mixer and digital amplifier in a 19" housing
Built-in USB audio interface allows recordings and playback of digital audio files with a computer (PC and Mac)
6 mono input channels with gain control, 2-way EQ, pan control and channel fader
2 stereo input channels with 2-way EQ, balance control and channel fader
8 channel inserts
Tape input and output
Separate main mix and control room outputs
2 AUX send outputs
Adjustable headphones output
+48 V phantom power, can be switched centrally
4-digit stereo LED level display
(19") 48.3 cm rack installation 3 U
Digital signal processor 24 bit with 16 effects
Control via IR remote control; Bluetooth
For application areas such as: Clubs/dancing school; stage; theater; concerts/FoH's; rental
