4-channel DJ mixer with Bluetooth and MP3 player
OMNITRONIC PM-422P 4-Channel DJ Mixer with Bluetooth & USB Player

download image
Detail images (5 overall)
svg
svg
svg
svg
svg
OMNITRONIC

4-channel DJ mixer with Bluetooth and MP3 player

OMNITRONIC PM-422P 4-Channel DJ Mixer with Bluetooth & USB Player

Stock for approx. 2 wk(s)
229,00 €
add to cart
Find a dealer
List price excl. 19% VAT
Prices in retail stores may vary.
Item no. 10006878
Print product
Product badge
Here you find the manual and downloads for
OMNITRONIC PM-422P 4-Channel DJ Mixer with Bluetooth & USB Player
OMNITRONIC PM-422P Cover picture
Omnitronic PM-422P

Fully equipped entry-level mixer for the tight budget


The PM-422P is a well-equipped 4-channel DJ mixer for the small budget. In addition to standard functions such as gain control, LED level meter, 3-band equalizer, cue button and channel fader, the PM-422P has a lot more to offer:
OMNITRONIC PM-422P Connections
Inputs
8 line and 2 phono inputs are available via cinch sockets. The PM-422P's 4 channels offer high flexibility during the DJ set and allow quick switching between multiple DJs.
OMNITRONIC PM-422P
Monitoring and live recording
The master output can be monitored via balanced RCA and XLR outputs. The independent master rec-out also allows DJ mixes to be live recorded.
OMNITRONIC PM-422P top view
Wireless transmission via Bluetooth
In addition, the PM-422P offers an MP3 player with USB connection and blue LCD display. The integrated Bluetooth function ensures wireless music transmission from mobile phone, tablet or laptop. A microphone input including volume control, 2-band equalizer and talkover switch for announcements complete the complete equipment package.
Features

4-channel DJ mixer with Bluetooth and MP3 player

  • 4 input channels with gain control, LED level meter, 3-band equalizer, cue button and channel fader
  • DJ microphone channel with level control, 2-band equalizer, on/off and talkover switch
  • Pre-fader listening to all input channels and the master output via adjustable stereo headphones output
  • Crossfader with assignment switches and adjustable curve
  • Master channel with level and balance control
  • 10-digit stereo LED level meter
  • Adjustable monitor output
  • 10 line and 2 phono inputs via RCA jacks
  • Balanced XLR and RCA outputs
  • Record output, independent of the master
  • Control via Bluetooth
  • LCD display
  • Operating range up to 10m
  • Desktop console housing
  • For application areas such as: Party room; mobile djs / entertainer; mobile use

Package contents

  • 1 x mixer, 1 x user manual, 1 x power cord, 1 x rCA cable, 1 x declaration of conformity
Technical specifications
Power supply:100-240 V AC, 50/60 Hz
Power consumption:25 W
Protection class:Protection class II
Power connection:Mains input via C8 (M) "figure 8" mounting version power supply cord with Euro plug (provided)
Control:Bluetooth
Bluetooth:Version: 4,2 + EDR
Profiles: A2DP, AVRCP
Audio player:USB + Bluetooth
Range:Range up to 10m
Carrier frequency:2,4 GHz
Display type:LCD display
Control elements:Audio player, Talkover, Crossfader selector switch, Crossfader, Crossfade curve switch
Status LED:Chanal level meter, master level meter, CUE, ON AIR, power
Connections:Input: line via 6 x stereo RCA
Input: line/phono via 2 x stereo RCA
Input: Microphone via 1 x 6.3 mm jack socket (mono) mounting version
Input: Audio player via 1 x USB A (F) mounting version
Output: master via 1 x stereo RCA
Output: master via 2 x 3-pin XLR
Output: rec. via 1 x stereo RCA
Output: booth via 1 x stereo RCA
Output: headphones via 1 x 6.3 mm jack socket (stereo) mounting version
Channels:Input chanel: 1 x stereo with Line-line-player switch via RCA or player, channel control via fader, 3-band tone control EQ, gain control, CUE switch
Input chanel: 1 x stereo with Line-line switch via RCA, channel control via fader, 3-band tone control EQ, gain control, CUE switch
Input chanel: 2 x stereo with Line-Line/Phono switch via RCA, channel control via fader, 3-band tone control EQ, gain control, CUE switch
Microphon chanal: 1 x mono via Jack, channel control via Rotary dial, 2-band tone control EQ, Talkover switch, ON AIR switch
Master output: 1 x stereo via XLR or RCA, channel control via Rotary dial, balancecontrol
Booth output: 1 x stereo via RCA, channel control via Rotary dial, Cue-mix-function
Headphones output: 1 x stereo via Jack, channel control via Rotary dial
Music format:MP3, WAV; WAV
USB port:Typ A
Housing design:Desktop console housing
Dimensions:Length: 35 cm
Width: 26,6 cm
Height: 10,5 cm
Weight:3,46 kg
Audio player
Available storage media:USB devices max. 32GB (FAT 32)
Packaging units
PUEANWeightDimensions
140263976534104,17 kg37,1cm x 29,5cm x 12,55cm
240263976608148,80 kg40,5cm x 36cm x 31cm
Accessories
Loading accessories. Please wait...
Support
Spare parts
IC 4558D SMD
E6519698
Pcb (Bluetooth/Player) PM-322P (001-MIX03-005)
E6519714
Pcb (Power supply) PM-322P 12V/5V (BOS-101 REV1.0)
