| Power supply: | 230 V AC, 50 Hz, |
| via supplied power unit | |
| Inputs: | |
| DJ microphone: | combined XLR/6.3 mm jack (1/4") (bal.) |
| MIC 1, 2: | 6.3 mm jack (1/4") (bal.) |
| Minimum input voltage: | 1 mV RMS |
| LINE 1-10 (rear): | stereo RCA |
| LINE 8 (front): | stereo RCA/3.5 mm jack (1/8") |
| Minimum input voltage: | 150 mV RMS |
| PHONO 1, 2: | stereo RCA |
| Minimum input voltage: | 3 mV RMS |
| Outputs: | |
| MASTER 1: | stereo XLR/stereo RCA |
| Output voltage: | 0.75 V/1.5 V RMS (switchable) |
| MASTER 2: | 6.3 mm stereo jack |
| Output voltage: | 0.75 V/1.5 V RMS (switchable) |
| BOOTH: | stereo RCA |
| Output voltage: | 0.75 V |
| REC: | stereo RCA |
| Output voltage: | 0.75 V |
| Headphones output: | 3.5 mm/6.3 mm jack (1/8"/1/4") (min. 8 ohms) |
| X-FADER START: | 2 x 3.5 mm jack (1/8") |
| Tone control (DJ microphone): | |
| 1 x high: | -12 dB to +12 dB/ 10 kHz, ±1 dB |
| 1 x middle: | -12 dB to +12 dB/ 1 kHz, ±1 dB |
| 1 x low: | -12 dB to +12 dB/ 100 Hz, ±1 dB |
| Talkover attenuation: | -15 dB |
| Tone control (channel 1-4): | |
| 4 x high: | -26 dB to +12 dB/ 10 kHz, ±1 dB |
| 4 x middle: | -26 dB to +12 dB/ 1 kHz, ±1 dB |
| 4 x low: | -26 dB to +12 dB/ 100 Hz, ±1 dB |
| S/N ratio: | >75 dB |
| Distortion: | 0.03% |
| Dimensions (WxHxD): | 320 x 320 x 110 mm |
| Weight: | 5.4 kg |
| Power consumption: | 35.00 W |
| Frequency range: | 20 - 20000 Hz |
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 4026397380484 | 6,15 kg | 47cm x 38,5cm x 17cm |
| 3 | 4026397380491 | 19,90 kg | 52cm x 48cm x 41cm |
| Name | Version | Language |
|---|---|---|
| 00043116.pdf | 2.00 | de/en |
| Name | Version | Language |
|---|---|---|
| 00066997.pdf | 21.00 | de |
| 00067756.pdf | 21.00 | en |
| Name | Version | Language |
|---|---|---|
| Circuit diagram00063715.pdf | 1.00 | en |
| Name | Version | Language |
|---|---|---|
| 10006860.zip |
