Steinigke Showtechnic GmbH - your wholesale company for event technology. We only sell to commercial customers. All prices without tax.
10451180

OMNITRONIC P-2000 Amplifier, 2x1000W/4ohm

Loader
Loader
Les photos de cet article sont en cours de chargement. Merci de patienter...
This product has the successor:
OMNITRONIC SMA-2000 Amplifier
OMNITRONIC
P-2000 Amplifier, 2x1000W/4ohm

Powerful PA amplifier for large stages

Art. n° 10451180

  • 2 x 1000 W/4 ohm
  • Enormous power with highest brilliance
  • 2 gain controls on the front panel
  • All operation modes controllable via LEDs
  • LED intensity adjustable via brightness control on the rear panel
  • Signal inputs via XLR female or 6.3 mm jack socket
  • Input sensitivity adjustable via selector on the rear panel
  • Speaker connection via lockable Speaker plugs or Banana/screw combination
  • With limiter
  • Ground Lift switch against humming
  • Bridged switch for bridging
  • Many protection circuits for optimized equipment protection
  • Very rugged housing
  • Rack installation
  • High power/weight-relation
Power supply:115/230 V AC, 50/60 Hz
Power range:230 V ±10 % (207-253 V)
Power consumption:3500 W
Power output sine:
Stereo 4 ohms2 x 1000 W
Stereo 8 ohms2 x 625 W
8 ohms bridged1 x 1875 W
Frequency range:40-40000 Hz, ±3 dB
Damping factor:>400
Distortion factor:0.01 %
Signal-to-noise ratio:90 dB
Channel seperation (at 1 kHz):70 dB
Min. input sensitivity:0.77 V/26 dB/1.4 V
Input impedance:20 kohms (balanced)
Slew rate:60 V/µsec
Input connectors:2 x XLR female plug, 2 x 6.3 mm jack plug
Output connectors:2 x Speaker (stereo), 1 x Speaker (bridge), 2 x Banana/screw combination
Control elements:Power switch, input attenuators (one per channel), Mode switch - Stereo/Parallel/Bridged, Ground Lift, Input-Level-Select (0.77 V/26 dB/1.44 V), limiter
LED indicators (per channel):Power, Protect, Signal, Mode
Protection circuits:Short-circuit, DCt, thermal, softstart
Construction:Steel chassis, aluminum front panel
Dimensions:490 x 482 x 100 mm
Minimum mounting depth:510 mm
Weight:17 kg
Conditionnement EAN Poids Dimensions
1 4026397145861 18.500 kg 51cm x 49cm x 15cm
