OMNITRONIC DEQ-231 Digital EQ 2x31-bands

Loader
Loader
Les photos de cet article sont en cours de chargement. Merci de patienter...
OMNITRONIC
DEQ-231 Digital EQ 2x31-bands

2 x 31-band digital equalizer

Art. n° 10356120

  • Gain control in 0.5 dB steps up to 16 dB
  • 24 Bit dual DSP
  • 48 kHz sampling rate Sigma-Delta, A/D, D/A converter
  • Intergrated digital Noise Gate
  • 100 programs can be memorized via battery backup
  • Left/right copying function
  • Lock function
  • MIDI control possible
  • Rack installation, 1 U
Power supply:115/230 V AC, 50/60 Hz ~
Power consumption:10 W
Inputs:XLR or balanced 6.3 mm jack
Nominal Operating Level:-20 dB to +4 dB
Max. input level:+16 dB at +4 dB nominal level, +2 dB at -20 dB nominal level
Input impedance:40 ohms balanced, 20 ohms unbalanced
Outputs:XLR or balanced 6.3 mm jack
Max. output level:+16 dB at +4 dB nominal level, +2 dB at -20 dB nominal level
Output impedance:66 ohms balanced, 33 ohms unbalanced
Frequency range:20-20000 Hz
Distortion:0.06 %
S/N-ratio:98 dB, 20-20000 Hz
Crosstalk:-95 dB, 20-20000 Hz
MIDI-Interface:5-pin DIN-socket IN/OUT/THRU
Converters:24-bit Sigma-Delta, 64/128-times oversampling
Sampling rate:48 kHz
Dimensions (WxDxH):482 x 152 x 45 mm
Weight:3 kg
Shipping weight:2.90 kg
Conditionnement EAN Poids Dimensions
1 4026397177749 2.900 kg 52cm x 25cm x 8.5cm
10 4026397179293 0.000 kg 0cm x 0cm x 0cm
